Create a Basic Action

This guide walks you through creating a custom Action using the createAction() function.

---

1. Basics

Before creating the action, let's quickly review some basic concepts and terms you should know:

What Is a Namespace?

Namespaces make sure that every element, action, and dynamic property has a globally unique ID. They help prevent naming conflicts between the elements found in your Extensions. Think of a namespace as a unique prefix that helps keep your code organized and conflict-free.

It's like putting all the stuff from your extension into its own folder so it doesn't accidentally clash with anything else in your HELIO projects.

Why Do Namespaces Matter?

Take, for example, a custom element named StatusIndicator. Multiple developers or even multiple companies might use the same names for such an element. Without namespaces, that could lead to conflicts or unexpected behavior. By giving your extension its own namespace, you make sure everything stays clean and separated — no mix-ups, no surprises.

What Does a Namespace Look Like?

Your namespace becomes part of the unique ID of your Custom Elements. So in our example, the custom element named StatusIndicator is part of the my-extension namespace of your company. So the namespace would be com.my-company.my-extension and the actual ID of your element will be: com.my-company.my-extension.StatusIndicator. This ensures that this ID will never collide with elements from other extensions, or companies, even if other extensions use the same element name StatusIndicator.

What Is an Action?

An Element is a fundamental building block of an HMI — a control, widget or visual component that you can add to a page and configure. Think of it like a ready-made piece of interface.

Elements

• Render visual content in the HMI.
• Appear in the HELIO IDE's Add Element dialog in the Project Editor.
• Are configured using properties that are displayed in the Properties Panel of the Project Editor.
• Can be placed in specific parts of an HMI based on their Traits.

Custom Elements Let You

• Create custom UI controls (buttons, gauges, dashboards, etc.) that are tailored to your needs.
• Encapsulate visual logic and interactivity, so you can reuse them across projects.
• Enhance and extend the HELIO library with functionality you need that isn't available out of the box.

What Is a Props Schema?

A Props Schema lets you configure the API for whatever you build with the SDK — like Custom Elements, Custom Actions, and custom Dynamic Properties. It lets you control what properties your users can configure in the HELIO IDE.

These properties will show up in the Properties Panel of the Project Editor whenever an item of your extension is added or selected.

You define a props schemas by using the createPropsSchema() function.

Props Schemas Specify

• What properties are available and how they are called
• The types of these properties (text, numbers, etc.)
• The default property values for new instances
• Validation rules

---

2. Example

Here's an example of a basic custom action that shows a native alert using the browser's built-in alert() method.

import { createAction, createPropsSchema } from '@hmiproject/helio-sdk';
import { namespace } from '../../namespace';

export const basicAction = createAction(namespace, {
  name: 'Basic Action',
  description: 'Displays an alert',
  icon: { name: 'Runner' },

  propsSchema: createPropsSchema().initial({}),

  useAction() {
    return {
      canCall: true,

      call() {
        alert('Action called');
      },
    };
  },
});

L1

Import the necessary functions from the SDK. The createAction() function is the core function for defining actions, while createPropsSchema() is a utility supporting it.

L2

Every element needs to live within a Namespace to prevent naming conflicts. Here you import the namespace you have created in the Create a Namespace guide.

L4

Use createAction() to create the action in your namespace and export it so you can later use it in other modules.

L5-6

The name and description are shown inside the Select Action dialog in the IDE. Pick these so that your users can easily understand what this element does.

L9

The propsSchema property defines the properties of your element that can be edited in the HELIO IDE with the help of a Props Schema. Since this action is super simple, no properties are defined.

L11-19

The useAction function defines how your action behaves. It returns an object with:

• canCall: Whether the action is currently executable (boolean)
• call(): What happens when the action runs

This example always allows execution (canCall: true) and displays a browser alert when called.

---

Mission accomplished!

Congratulations! You now understand the basic structure of custom actions.
